In water heating, oil and gas, and industrial fluid transportation projects, traditional pipe joints mostly adopt traditional threaded welding and hot-melt connection methods. These methods have problems such as cumbersome installation, long construction period, limited compatibility with media types, and poor pressure stability. Over time, they are prone to interface loosening, leakage, oxidation corrosion, etc., which affect the stable operation of the pipeline system. Moreover, most ordinary joints have a narrow temperature and pressure tolerance range and cannot be adapted to special medium transportation scenarios such as weak acids and weak bases, thus limiting their applicable scenarios.
Press-fit Brass Straight Connector for Fluid Lines is made of high-quality brass and is forged to form a sturdy structure. It is resistant to oxidation and corrosion and has extremely strong adaptability to working conditions. The product adopts a quick-insert installation structure, eliminating the cumbersome processes of welding and threaded connection, significantly improving the efficiency of pipeline installation. The rated pressure is 1.6MPa - 4.0MPa, and the working temperature range covers -10℃ to 120℃. It can stably transport various fluid media such as water, oil, gas, and weak acids and weak bases.
|
Product Size |
Aluminum Plastic Composite Pipe T |
d1 |
d2 |
d3 |
L |
Product Materials |
|||
|
16mm–16mm |
2.0mm |
7.5 |
11.80 |
16.5 |
51.2 |
CW617 |
PE |
SUS304 |
EPDM |
|
20mm–20mm |
2.0mm |
10.5 |
15.80 |
20.5 |
52.1 |
||||
|
25mm–25mm |
2.5mm |
15.0 |
19.80 |
25.5 |
65.9 |
||||
|
32mm–32mm |
3.0mm |
20.0 |
25.75 |
32.5 |
66.3 |
||||
|
40mm–40mm |
4.0mm |
25.0 |
31.75 |
40.5 |
94.6 |
||||
|
50mm–50mm |
4.5mm |
34.0 |
40.75 |
50.5 |
95.6 |
||||
|
63mm–63mm |
6.0mm |
42.0 |
50.75 |
63.5 |
139.4 |
CW617 |
PE |
SUS304 |
EPDM |
The valve body is formed by processing with high-quality brass raw materials in one piece. The structure is dense and tight, without sand holes or gas pores, etc. The overall structure has high strength and is not prone to deformation or cracking.
The brass base material inherently has excellent anti-rust and anti-corrosion properties. It can resist air oxidation and medium erosion, and is suitable for the transportation of special fluids such as weak acids and weak alkalis. It is not prone to rusting and aging over a long period of use.
The material has a balanced hardness and toughness. Under the conditions of pipeline vibration and temperature-pressure fluctuations, it can maintain the integrity of the joint structure, and prevent interface deformation and loosening from causing leakage problems.
The standard nominal pressure range is from 1.6 MPa to 4.0 MPa, suitable for high-pressure transportation in conventional civilian pipelines, commercial fluid pipelines, and light industrial pipelines. The pressure-bearing is stable without leakage.
Press-fit Brass Straight Connector for Fluid Lines can operate continuously and stably in a temperature range from -10°C to 120°C, capable of withstanding the temperature differences throughout the year and the alternating impacts of cold and hot conditions of the pipelines. The performance does not deteriorate in both high and low temperature environments.
Suitable for the transportation of various fluid media such as water, oil products, conventional gases, weak acids, and weak bases. It breaks the single-medium usage limitation of ordinary joints and is compatible with multiple scenarios for pipeline renovation and new installation projects.
Adopting a mature quick-insert structure design, it eliminates the cumbersome processes of heat fusion, welding, and winding of protective tape. The pipe connection is simple and fast, significantly shortening the on-site construction period.
The exclusive straight-through connection structure ensures a tight fit after the pipe is inserted, with high coaxiality. This effectively avoids interface misalignment and water leakage or air leakage problems, ensuring the pipe's sealing performance.
The modular quick-insert structure supports non-destructive disassembly. Later pipe maintenance, renovation, and replacement do not require cutting the pipe material, thereby reducing the pipe operation cost and construction loss.
The product is compatible with the mainstream pipeline installation standards in Europe, America, Japan and South Korea. After being tested in various regional working conditions, it has a high market share and is suitable for large-scale HVAC and fluid pipeline projects in overseas regions.
Targeted optimization of branch pipeline connection performance, perfectly adapting to various fluid system branch diversion and connection points, and meeting the requirements of precise pipeline layout construction.
Standardized specification design, compatible with mainstream pipe material specifications in the market. Whether it is a new pipeline installation project or an old pipeline renovation project, it can be directly replaced and adapted, with full universality.
Before each batch of Press-fit Brass Straight Connector for Fluid Lines leaves the factory, strict water pressure pressure-bearing tests, air tightness tests and thread accuracy checks are conducted to ensure that there are no issues such as insufficient pressure-bearing capacity, alignment deviations, or sealing failures.
All production, processing, and testing records of the products are uniformly archived and retained. Each batch of goods can be traced throughout the process, ensuring the stability of product quality from the source.
We can provide a complete set of material test reports, finished product inspection certificates, and batch quality inspection documents, meeting various engineering acceptance standards and cross-border trade review requirements.
For each shipment, we can simultaneously provide official origin certificates and complete quality inspection materials, helping overseas customers quickly complete customs clearance and avoid trade process obstacles.
We have a professional technical team that provides technical consultation services throughout the process, including pipeline selection, installation and commissioning, and fault diagnosis, to quickly solve various operational problems encountered by customers during use.
The factory conducts large-scale production, has sufficient inventory reserves, and can undertake large-scale engineering orders from both domestic and overseas markets, ensuring supply efficiency and meeting the requirements for long-term stable cooperation and procurement.
Suitable for branch connections of household water supply and heating water pipelines. Installation is quick and stable, compatible with common temperature and pressure conditions in households, and the construction is convenient and aesthetically pleasing.
Suitable for central air conditioning and centralized heating fluid pipelines in commercial buildings. The multi-medium adaptability meets the complex pipeline transportation requirements of commercial settings.
Can be used for industrial light fluid pipelines such as oil, gas, weak acids, and weak bases. The wide temperature pressure performance is compatible with industrial complex conditions.
Complies with the pipeline construction standards of Europe, America, Japan, and South Korea. Suitable for overseas batch infrastructure and HVAC renovation projects. It is the preferred accessory for cross-border fluid pipeline support.
A: Traditional threaded joints are cumbersome to install, require manual material winding, and are prone to slippage and leakage, resulting in low construction efficiency. This product adopts a quick-insert structure, eliminating the need for welding and complicated threading operations. It installs faster and has stronger sealing stability. Additionally, it is compatible with multiple media and wide temperature pressure conditions, and its overall practicality far exceeds traditional joints.
A: Yes. The Press-fit Brass Straight Connector for Fluid Lines has been tested under multiple media conditions and is suitable for both regular water and oil media, as well as the stable transportation of common gases, weak acids, and weak alkalis, meeting the transportation needs of various light industrial scenarios.
A: No. The product's temperature tolerance range is -10°C to 120°C. Under normal cold and hot alternating, low-temperature anti-freezing, and high-temperature water supply conditions, the structure and sealing performance can remain stable, and there will be no cracking, leakage, or detachment issues.
A: Absolutely. The 1.6 MPa - 4.0 MPa wide pressure rating range covers the vast majority of industrial scenarios for home decoration plumbing, commercial HVAC, and light industrial fluid pipelines, with sufficient pressure safety redundancy.
