Female Thread Compression Butterfly Handle Ball Valve

In scenarios such as small equipment cabinets, precise instrument pipelines, and concealed water supply systems in home decoration, conventional external thread valves and large-handle valves often have problems such as incompatible interfaces, insufficient operation space, and complicated welding construction. This Female Thread Compression Butterfly Handle Ball Valve is specially designed for the internal thread end of the equipment. Relying on the dual interface structure of direct connection with internal thread and non-welded sleeve, it completely simplifies the assembly process of precise pipelines. Combined with the ultra-thin butterfly handle for narrow-space operation, the forged brass valve body and composite sealing structure ensure stable zero leakage in cold and hot water circulation pipelines, and balance water flow efficiency and usage safety.

Product Features

1. Exclusive internal connection structure: One end of the valve body has precise internal thread, which precisely matches various small equipment and instrument hosts with external teeth interfaces. There is no need for intermediate connectors, and the pipe connection is more regular, reducing the potential water leakage hazards caused by redundant connection nodes.

2. Weld-free quick-install design: The terminal adopts a standard card sleeve locking structure, which can firmly hold the copper pipe and the instrument steel pipe. The entire process does not require welding, hot melting, or gluing, avoiding the restrictions of on-site firework operations, and is suitable for indoor decoration, precision instrument equipment installation scenarios.

3. Ultra-thin butterfly handle minimalist design: The Female Thread Compression Butterfly Handle Ball Valve adopts a flat butterfly handle without redundant protruding structures. Compared with the conventional handle, it significantly saves installation space. It can be easily opened and closed in 90° positions in pipe gaps, sealed cabinets, ceiling concealed installation, and other restricted positions.

4. High-density sealing and large flow configuration: The chrome-plated ball body is combined with a thickened Teflon valve seat to achieve bidirectional sealing with zero leakage. The pressure drop loss in the full diameter internal cavity is extremely low. Combined with the anti-blowout valve stem structure, it can adapt to daily water pressure fluctuations and does not age or leak over long-term cold and hot circulation water.

5. Lead-free forged brass base material: Integrated forging of anti-zinc loss lead-free brass, with dense texture, high pressure resistance, anti-scaling, and anti-corrosion, no heavy metal emissions, and in line with the safety usage standards for domestic drinking water and precision equipment circulating water.

Technical parameters

Product Function

1. Achieve precise water control at the equipment end and independent zone management: Specifically designed for the water flow control at the wire interface end of the equipment main unit. It can independently control the water flow of the instrument, floor heating, and home decoration branch lines. During equipment maintenance and pipeline repair, there is no need to shut down the entire water system, making operation more convenient.

2. Simplify pipeline structure and reduce construction costs: The internal wire directly connects to the equipment, eliminating the need for adapter components. The ferrule does not require welding, eliminating construction materials and equipment, significantly simplifying the pipeline layout, shortening the installation period, and reducing leakage points, as well as lowering the long-term maintenance costs.

3. Solve the problem of narrow space control and adapt to concealed pipelines: For scenarios without operation space such as equipment cabinets, wall gaps, and concealed ceiling installation, it realizes unobstructed on-site control. Female Thread Compression Butterfly Handle Ball Valve takes into account the concealment installation aesthetics and operational convenience of the pipeline and the long-term operability in the future.

4. Stabilize and protect terminal equipment, extend equipment lifespan: The sealing performance is stable, which can prevent water leakage and dripping problems. It avoids water accumulation from corroding precision instruments, floor heating units, and home decoration water and heating accessories, effectively ensuring the long-term stable operation of the terminal equipment.

Application scenario

1. Concealed water supply pipeline for home decoration: Suitable for concealed underground installation in walls and hidden water supply branch control in ceilings. The ultra-thin handle does not occupy the decoration space. The non-welding process is compatible with the decoration construction standards for home decoration, and there is no fire safety hazard.

2. Household and commercial floor heating circulation system: Used for the branch circuits of floor heating distribution valves and the water control in the narrow space of floor heating cabinets, compatible with the floor heating heating and cooling circulation conditions. The flow is smooth without affecting the heating efficiency, and the disassembly and assembly are convenient for the maintenance of the floor heating pipeline.

3. Small precision instrument circulation waterway: Suitable for the built-in circulation waterways of detection instruments, small temperature control devices, and experimental devices. Precisely connect to the threaded interfaces inside the equipment, lock the special steel pipe for the instrument, and ensure zero leakage operation of the waterway for precision equipment.

4. Small commercial lightweight water circulation system: Small water supply renovation for shops and offices, lightweight industrial circulation waterway, compatible with small flow and stable water pressure conditions, suitable for batch lightweight pipeline procurement.

Quality Control and After-sales Guarantee

1. Raw material spectral traceability testing: All raw brass materials entering the factory undergo spectral composition analysis. Strict control is exerted on core indicators such as lead-free content, anti-deoxidation, and corrosion resistance, ensuring that the valve body is suitable for long-term water supply conditions from the source.

2. 100% full inspection of finished products: Each Female Thread Compression Butterfly Handle Ball Valve passes water pressure resistance, airtightness prevention leakage, and ten-thousand times opening and closing durability tests. Only after meeting the comprehensive requirements of basic pressure-bearing, sealing, and wear resistance can it be stored.

3. Scenario-specific precision calibration: Special tests are conducted for the unique internal thread accuracy, clamping force of the adapter sleeve, and opening and closing torque in the narrow space of the butterfly handle to prevent specific problems such as internal thread loosening, pipe material slippage, and handle jamming.

4. Full batch traceability + complete qualifications: The product has an independent batch code, and the entire production process is traceable. When shipping, material testing reports and CE certificates can be provided, fully meeting the requirements of engineering bidding, overseas customs clearance, and project acceptance.

5. Factory warranty and customized services: Provide 12 months factory warranty. The technical team can provide internal thread equipment connection, adapter sleeve assembly, pipeline debugging, and leakage detection special guidance. Global customers can be connected in multiple languages. Customized solutions and long-term spare parts supply can be provided for batch projects.

What's the difference from the Male Thread Ferrule Brass Ball Valve with Butterfly Handle?

1. The core connection interface is completely opposite: This product has an internal thread port, which is used to connect to the external thread connectors of equipment and pipe fittings; the external thread handle ball valve has an external tooth port, which is used to connect to the internal thread base. The two interfaces are complementary and cannot be used interchangeably. They are complementary accessories for the upstream and downstream of the pipeline.

2. The installation position and compatible equipment are different: This internal thread model is more suitable for the internal installation of equipment bodies, suitable for embedded assembly of instruments and small equipment hosts; the external thread model is mostly used for extending the pipe outside, for connecting the exposed pipe lines, and is more suitable for the renovation of exposed water heating pipe lines.

3. The construction compatibility scenarios have clear distinctions: The internal thread model mainly focuses on sealed, narrow, and embedded space construction, suitable for precision equipment and concealed home decoration pipe lines; the external thread model has stronger versatility, mostly used for conventional exposed floor heating, home decoration exposed pipe lines, and is more demanding on the operation space.

4. The procurement matching purposes are different: The internal thread handle ball valve is mostly used for equipment original factory whole machine matching and standard water supply lines for precision instruments; the external thread handle ball valve is mostly used for terminal home decoration renovation, water heating engineering after-sales maintenance, and pipe line expansion matching.
